Quick Release Pins, Button Handle
Quick Release Pins, Button Handle with ball lock , material by stainless steel, size 3/16″-5/8″, M5-M20 from professional quick release pins in China
Quick Release Pins
Quick Release Pins Material:
Shank: Stainless Steel SUS304
Button: Brass HPb59-1
Spring: Stainless Steel SUS304
Handle: Stainless Steel SUS304
Ring: Stainless Steel SUS304
Ball: Stainless steel
 |
 |
Quick Release Pins, Button Handle Inch Size :
| Item | Shank | Length |
| Quick Release Pins, Button Handle | 3/16″ | 0.5-2″ |
| Quick Release Pins, Button Handle | 1/4″ | 0.5-4″ |
| Quick Release Pins, Button Handle | 5/16″ | 0.75-5″ |
| Quick Release Pins, Button Handle | 3/8″ | 0.75-6″ |
| Quick Release Pins, Button Handle | 7/16″ | 1-6″ |
| Quick Release Pins, Button Handle | 1/2″ | 1.25-7″ |
| Quick Release Pins, Button Handle | 5/8″ | 1.5-7″ |
Quick Release Pins, Button Handle Metric size:
| Item | Shank | Length |
| Quick Release Pins, Button Handle | 5mm | 15mm-75mm |
| Quick Release Pins, Button Handle | 6mm | 15mm-75mm |
| Quick Release Pins, Button Handle | 8mm | 15mm-100mm |
| Quick Release Pins, Button Handle | 10mm | 15mm-125mm |
| Quick Release Pins, Button Handle | 12mm | 20mm-180mm |
| Quick Release Pins, Button Handle | 16mm | 20mm-180mm |
| Quick Release Pins, Button Handle | 20mm | 25mm-200mm |
